Produktsäule： Rechteckige Anschlüsse >>Einsätze >>HM Modulare Insert -Serie >>Leistungsmodul

Module size:Single module,Connection type:Axial bolt connection,Male/female:Male,Number of connector contacts:2,Rated current:40A,Rated voltage:1000V,Insulation resistance:≥10¹ºΩ,Inserts material:Polycarbonate,Contact material:Copper alloy,Wire gauge (mm²):2.5-8mm²,Wire gauge (AWG):NA,Tightening/testing Drehmoment: 2,5 mm² → 1,5 nm | 4mm² → 1,5 nm | 6mm² → 2nm

Produktsäule： Rechteckige Anschlüsse >>Einsätze >>HM Modulare Insert -Serie >>Leistungsmodul

Module size:Single module,Connection type:Axial bolt connection,Male/female:Female,Number of connector contacts:2,Rated current:40A,Rated voltage:1000V,Insulation resistance:≥10¹ºΩ,Inserts material:Polycarbonate,Contact material:Copper alloy,Wire gauge (mm²):2.5-8mm²,Wire gauge (AWG):NA,Tightening/testing Drehmoment: 2,5 mm² → 1,5 nm | 4mm² → 1,5 nm | 6mm² → 2nm

Produktsäule： Rechteckige Anschlüsse >>Einsätze >>HM Modulare Insert -Serie >>Leistungsmodul

Module size:Single module,Connection type:Axial bolt connection,Male/female:Male,Number of connector contacts:2,Rated current:40A,Rated voltage:1000V,Insulation resistance:≥10¹ºΩ,Inserts material:Polycarbonate,Contact material:Copper alloy,Wire gauge (mm²):6-10mm²,Wire gauge (AWG):NA,Tightening/testing Drehmoment: 6mm² → 2nm | 10mm² → 2nm

Produktsäule： Rechteckige Anschlüsse >>Einsätze >>HM Modulare Insert -Serie >>Leistungsmodul

Module size:Single module,Connection type:Axial bolt connection,Male/female:Female,Number of connector contacts:2,Rated current:40A,Rated voltage:1000V,Insulation resistance:≥10¹ºΩ,Inserts material:Polycarbonate,Contact material:Copper alloy,Wire gauge (mm²):6-10mm²,Wire gauge (AWG):NA,Tightening/testing Drehmoment: 6mm² → 2nm | 10mm² → 2nm

Produktsäule： Rechteckige Anschlüsse >>Einsätze >>HM Modulare Insert -Serie >>Leistungsmodul

Module size:Single module,Connection type:Axial bolt connection,Male/female:Male,Number of connector contacts:3,Rated current:40A,Rated voltage:690V,Insulation resistance:≥10¹ºΩ,Inserts material:Polycarbonate,Contact material:Copper alloy,Wire gauge (mm²):2.5-8mm²,Wire gauge (AWG):NA,Tightening/testing Drehmoment: 2,5 mm² → 1,5 nm | 4mm² → 1,5 nm | 6mm² → 2nm

Produktsäule： Rechteckige Anschlüsse >>Einsätze >>HM Modulare Insert -Serie >>Leistungsmodul

Insulation resistance:≥10¹ºΩ,Inserts material:Polycarbonate,Contact material:Copper alloy,Wire gauge (mm²):2.5-8mm²,Wire gauge (AWG):NA,Tightening/testing torque:2.5mm²→1.5Nm|4mm²→1.5Nm|6mm²→2Nm,Module size:Single module,Connection type:Axial bolt connection,Male/female:Female,Number of Steckerkontakte: 3, Nennstrom: 40a, Nennspannung: 690 V

Produktsäule： Rechteckige Anschlüsse >>Einsätze >>HM Modulare Insert -Serie >>Leistungsmodul

Module size:Single module,Connection type:Axial bolt connection,Male/female:Male,Number of connector contacts:3,Rated current:40A,Rated voltage:690V,Insulation resistance:≥10¹ºΩ,Inserts material:Polycarbonate,Contact material:Copper alloy,Wire gauge (mm²):6-10mm²,Wire gauge (AWG):10-8 AWG,Tightening/testing Drehmoment: 6mm² → 2nm | 10mm² → 2nm

Produktsäule： Rechteckige Anschlüsse >>Einsätze >>HM Modulare Insert -Serie >>Leistungsmodul

Modulgröße: Einzelmodul, Anschlusstyp: Axialschraubenanschluss, männlich/weiblich: weiblich, Anzahl der Anschlüssekontakte: 3, Nennstrom: 40a, Nennspannung: 690 V, Isolationswiderstand: ≥10¹ºω, Einsätze Material: Polycarbonat, Kontaktmaterial: Kupferlegierung, MMM²). Drehmoment: 6mm² → 2nm | 10mm² → 2nm
